Object Relational Mapping Frameworks

Object Relational Mapping

Object-relational mapping (ORM, O/RM, and O/R mapping) in computer software is a programming technique for converting data between incompatible type systems in object-oriented programming languages. This creates, in effect, a "virtual object database" that can be used from within the programming language. There are both free and commercial packages available that perform object-relational mapping, although some programmers opt to create their own ORM tools.

Data management tasks in object-oriented (OO) programming are typically implemented by manipulating objects that are almost always non-scalar values. For example, consider an address book entry that represents a single person along with zero or more phone numbers and zero or more addresses. This could be modeled in an object-oriented implementation by a "Person object" with attributes/fields to hold each data item that the entry comprises: the person's name, a list of phone numbers, and a list of addresses. The list of phone numbers would itself contain "PhoneNumber objects" and so on. The address book entry is treated as a single object by the programming language (it can be referenced by a single variable containing a pointer to the object, for instance). Various methods can be associated with the object, such as a method to return the preferred phone number, the home address, and so on.

However, many popular database products such as structured query language database management systems (SQL DBMS) can only store and manipulate scalar values such as integers and strings organized within tables. The programmer must either convert the object values into groups of simpler values for storage in the database (and convert them back upon retrieval), or only use simple scalar values within the program. Object-relational mapping is used to implement the first approach.

The heart of the problem is translating the logical representation of the objects into an atomized form that is capable of being stored on the database, while somehow preserving the properties of the objects and their relationships so that they can be reloaded as an object when needed. If this storage and retrieval functionality is implemented, the objects are then said to be persistent.



Plain Old Java Object

In computing software, POJO is an acronym for Plain Old Java Object. The name is used to emphasize that a given object is an ordinary Java Object, not a special object. The term was coined by Martin Fowler, Rebecca Parsons and Josh MacKenzie in September 2000: "We wondered why people were so against using regular objects in their systems and concluded that it was because simple objects lacked a fancy name. So we gave them one, and it's caught on very nicely."

The term "POJO" is mainly used to denote a Java object which does not follow any of the major Java object models, conventions, or frameworks. The term continues the pattern of older terms for technologies that do not use fancy new features, such as POTS (Plain Old Telephone Service) in telephony, PODS (Plain Old Data Structures) that are defined in C++ but use only C language features, and POD (Plain Old Documentation) in Perl. The equivalent to POJO on the .NET framework is Plain Old CLR Object (POCO). For PHP, it is Plain Old PHP Object (POPO).

The POJO phenomenon has most likely gained widespread acceptance because of the need for a common and easily understood term that contrasts with complicated object frameworks.



Java Data Objects

Java Data Objects (JDO) is a specification of Java object persistence. One of its features is a transparency of the persistence services to the domain model. JDO persistent objects are ordinary Java programming language classes (POJOs); there is no requirement for them to implement certain interfaces or extend from special classes. JDO 1.0 was developed under the Java Community Process as JSR 12. JDO 2.0 was developed under JSR 243 and was released on May 10, 2006. JDO 2.1 was completed in Feb 2008, developed by the Apache JDO project. JDO 2.2 was released in October 2008. JDO 3.0 was released in April 2010.

Object persistence is defined in the external XML metafiles, which may have vendor-specific extensions. JDO vendors provide developers with enhancers, which modify compiled Java class files so they can be transparently persisted. (Note that byte-code enhancement is not mandated by the JDO specification, although it is the commonly used mechanism for implementing the JDO specification's requirements.) Currently, JDO vendors offer several options for persistence, e.g. to RDBMS, to OODB, or to files.

JDO enhanced classes are portable across different vendors' implementation. Once enhanced, a Java class can be used with any vendor's JDO product.

JDO is integrated with Java EE in several ways. First of all, the vendor implementation may be provided as a JEE Connector. Secondly, JDO may work in the context of JEE transaction services.



iBATIS

iBATIS is a persistence framework which automates the mapping between SQL databases and objects in Java, .NET, and Ruby on Rails. In Java, the objects are POJOs (Plain Old Java Objects). The mappings are decoupled from the application logic by packaging the SQL statements in XML configuration files. The result is a significant reduction in the amount of code that a developer needs to access a relational database using lower level APIs like JDBC and ODBC.

Other persistence frameworks such as Hibernate allow the creation of an object model (in Java, say) by the user, and create and maintain the relational database automatically. iBATIS takes the reverse approach: the developer starts with an SQL database and iBATIS automates the creation of the Java objects. Both approaches have advantages, and iBATIS is a good choice when the developer does not have full control over the SQL database schema. For example, an application may need to access an existing SQL database used by other software, or access a new database whose schema is not fully under the application developer's control, such as when a specialized database design team has created the schema and carefully optimized it for high performance.

On May 21, 2010 the development team decided to move from ASF to Google Code, changing the project name to MyBatis and making new releases there. As a consequence the Apache iBATIS project became inactive and was moved to the Apache Attic in June 2010.



Hibernate (Java)

Hibernate is an object-relational mapping (ORM) library for the Java language, providing a framework for mapping an object-oriented domain model to a traditional relational database. Hibernate solves object-relational impedance mismatch problems by replacing direct persistence-related database accesses with high-level object handling functions.

Hibernate is free software that is distributed under the GNU Lesser General Public License.
Hibernate's primary feature is mapping from Java classes to database tables (and from Java data types to SQL data types). Hibernate also provides data query and retrieval facilities. It also generates the SQL calls and attempts to relieve the developer from manual result set handling and object conversion and keep the application portable to all supported SQL databases with little performance overhead.

Mapping Java classes to database tables is accomplished through the configuration of an XML file or by using Java Annotations. When using an XML file, Hibernate can generate skeletal source code for the persistence classes. This is unnecessary when annotations are used. Hibernate can use the XML file or the annotations to maintain the database schema.

Facilities to arrange one-to-many and many-to-many relationships between classes are provided. In addition to managing associations between objects, Hibernate can also manage reflexive associations where an object has a one-to-many relationship with other instances of its own type.
Hibernate supports the mapping of custom value types. This makes the following scenarios possible:

  • Overriding the default SQL type that Hibernate chooses when mapping a column to a property.
  • Mapping Java Enum to columns as if they were regular properties.
  • Mapping a single property to multiple columns.
  • Persistence.

Hibernate provides transparent persistence for Plain Old Java Objects (POJOs). The only strict requirement for a persistent class is a no-argument constructor, not necessarily public. Proper behavior in some applications also requires special attention to the equals() and hashCode() methods.

Collections of data objects are typically stored in Java collection objects such as Set and List. Java generics, introduced in Java 5, are supported. Hibernate can be configured to lazy load associated collections. Lazy loading is the default as of Hibernate 3.

Related objects can be configured to cascade operations from one to the other. For example, a parent such as an Album object can be configured to cascade its save and/or delete operation to its child Track objects. This can reduce development time and ensure referential integrity. A dirty checking feature avoids unnecessary database write actions by performing SQL updates only on the modified fields of persistent objects.

Hibernate Query Language (HQL)

Hibernate provides an SQL inspired language called Hibernate Query Language (HQL) which allows SQL-like queries to be written against Hibernate's data objects. Criteria Queries are provided as an object-oriented alternative to HQL.

Integration

Hibernate can be used both in standalone Java applications and in Java EE applications using servlets, EJB session beans, and JBI service components. It can also be included as a feature in other programming languages. For example, Adobe integrated Hibernate into version 9 of ColdFusion (which runs on J2EE app servers) with an abstraction layer of new functions and syntax added into CFML.

Entities and components

In Hibernate jargon, an entity is a stand-alone object in Hibernate's persistent mechanism which can be manipulated independently of other objects. In contrast, a component is subordinate to other entities and can be manipulated only with respect to other entities. For example, an Album object may represent an entity but the Tracks object associated with the Album objects would represent a component of the Album entity if it is assumed that Tracks can only be saved or retrieved from the database through the Album object. Unlike J2EE, it can switch databases.
